Two Houston bathrooms that look identical from the doorway can be completely different jobs once
the wall is open. The reliable predictor is not the neighborhood name. It is the decade.
1900s–1940s
The Heights, Montrose, Woodland Heights, Norhill, Eastwood
Pier and beam over a crawl space, wood floor structure, shiplap or plaster behind the tile —
bathrooms often carved out of a sleeping porch or hallway after the house was built.
Original baths run tiny, frequently 5×7, with a cast-iron tub against the only wall that has plumbing in
it. The floor structure is accessible from below, which makes drain work far easier than on a slab and makes
true curbless achievable by dropping or sistering joists. It also means the framing is rarely square, supply
lines may still be galvanized, and pre-1978 lead-safe demolition applies to essentially every one of these
houses.
1950s–1970s
Memorial, Spring Branch, Meyerland, Sharpstown, Oak Forest, Garden
Oaks
This is the core of Houston walk-in shower work.
Spring Branch filled in with post-war subdivisions on former German farmland; Meyerland went up through the
1950s; Sharpstown was dedicated in 1955 as one of Houston's first master-planned suburbs. Conventional
slab-on-grade, no post-tension. Hall baths are commonly 5×8 with a 60×30 alcove holding a steel or cast-iron
tub, a two-handle valve, and a cast-iron drain line — the reason a conversion here is usually a one-day job.
The complication is Beaumont clay. Meyerland in particular has been through repeated flooding including
Harvey in 2017, and many homes there have been elevated, rebuilt or had floors replaced, so what you find
behind the wall may not match the original construction at all.
1920s–1970s estate
River Oaks, the Memorial Villages, West University Place
Estate stock — River Oaks from the 1920s, much of the Memorial Villages from the 1950s onward
on large wooded lots, with substantial rebuilding since.
Primary baths here are large, frequently already tiled, and often carry stone, custom glass, and multiple
valves. These are the projects where custom tile is usually the correct answer and a panel system is not
what the house wants. They are also where the permit authority is a separate city — covered in the permits
section.
Post-1990
Katy, Cinco Ranch, Cypress, Bridgeland, Fall Creek, The Woodlands
corridor
Post-tension slabs, engineered lumber, and a builder-grade primary-bath template repeated
across thousands of homes.
A garden-tub deck nobody has used in a decade next to a 36×36 or 42×36 fiberglass corner shower with a
plastic door. These convert beautifully, because the layout is already right and the plumbing rarely has to
move. They are also the homes where cutting the slab is a genuine hazard and where designing around the
existing drain is worth real money.
Era and areas
Foundation
Typical
bath
Shower opportunity
Watch for
1900s–1940s: Heights, Montrose, Norhill, Eastwood
Pier and beam over crawl space
5×7, cast-iron tub, added after original build
True curbless achievable by dropping joists
Out-of-square framing, galvanized supply, lead-safe demo
1950s–1970s: Memorial, Spring Branch, Meyerland, Sharpstown
Conventional slab-on-grade
5×8 hall bath, 60×30 tub alcove
One-day tub-to-shower conversion in the existing alcove
Cast-iron drain, clay movement, prior flood repairs in Meyerland
1920s–1970s estate: River Oaks, Memorial Villages, West U
Slab or pier and beam by vintage
Large primary bath, often already tiled
Custom tile, stone, frameless glass, multiple valves
Separate municipal permit authority, deed restrictions
1980s: Champions, Clear Lake, Kingwood, Fondren Southwest
Slab, early post-tension mid-decade
Garden tub plus separate stall
Convert the unused stall or the unused tub
Confirm whether the slab is post-tension before any cut
Post-1990: Katy, Cinco Ranch, Cypress, Bridgeland, Fall Creek
Post-tension slab
Garden-tub deck plus fiberglass corner unit
Direct swap, plumbing rarely moves
Never cut the slab without ground-penetrating-radar scanning
